Hybrid metal roof tiles
Price: CAD $
The Bratex Horizon hybrid metal roofing tile is a harmonious combination of a system product and an orderly roofing style. It is available in two variants - a sheet model with small dimensions or one cut to the desired size. It represents everything that is best for this class of product - it is convenient to transport, quick to install and durable in operation
Product description
Optimal sheet weight
The maximum length of up to 4 meters makes the hybrid metal roofing tile sheets lighter than the longest 8-meter conventional metal roofing tile sheets. After transporting to the roof surface, the sheets still retain their geometric parameters.
Compensation pocket
The use of a two-segment compensatory pocket with variable depth means that the sheets of the hybrid metal roof tile do not fall against the eaves, and the place of the corners of the four sheets is invisible.
Adjustable last module
The last module is adjustable in length and is always embossed with a 25 mm long tip (the so-called tongue). There is no need for a stable base for the installation of the ridge flashing, ventilation tape, no snow and rain blowing in and maintaining the overall width of the sheet.
Transport openings
At the end of each sheet (on the so-called tongue) there are two holes that allow it to be professionally pulled to the roof with ropes and prevent risky piercing of the sheet. Easy-Lift holes are punched for sheets of min. 4 modules.
Mounting points
Pre-drilled recessed mounting points indicate optimal screw locations for easy installation. They also reduce the risk of scratching the sheet metal and introduce consistency in the clamping system.
Easier transportation
The sheets of the hybrid metal roof tile are shorter in length, so they are easier to transport, move at the distributor's and moved on the construction site.
